WSFM1100-2000C Single Side Full Automatic High Speed Extrusion Laminating Machine

Application:  Paper PLA coating, Paper PBS coating, Paper PE coating,  etc. Main features: 1.PLC man-machine interface control, the design of mechanical electrical integration. 2.Shaftless unwinder, Auto splicing system. 3.Hydraulic compounding system, coating evenly

Send Inquiry
Shared to

Application:  Paper PLA coating, Paper PBS coating, Paper PE coating,  etc.



Main features:

1.PLC man-machine interface control, the design of mechanical electrical integration.

2.Shaftless unwinder, Auto splicing system.

3.Hydraulic compounding system, coating evenly

4.High precision and imported die head

5.High speed and efficient mixing equipment (Italy technology).

6.Automatic hydraulic filter screen exchange

7. Auto height-adjusting extruder

7.Heavy Friction rewinding system, rewinding roll more tight and beautiful

8.And can be matched with a single extruder, Twin Extruder, extruder, multilayer co-extrusion

It is widely used in paper cup, Paper trays, paper bag,  fast food paper containers, etc.



The main technical parameters:

machinery specification

1100/90mm、1300/100mm 、1500/105mm、 1800/110mm

speed of coating film

300m/min

suitable coating resin film

PLA、PBS\ LDPE、PP、 EVA 、EAA、

suitable base material

PAPER、AL、BOPP、BOPET、BOPA、CPP、CPE、

width of coating film

1000mm、1200mm、1400mm、1700mm

thickness of coating film

0.012~0.1mm

inaccuracy thickness of coating film

≦±5%

complex cooling roller

Φ800mm

screw specification

（L/D）Φ90：33、Φ100：33、Φ105:33；Φ110:33

main unwinding diameter

Φ1600mm

diameter of auxiliary unwinding

Φ600mm

diameter of rewinding

Φ1700mm
